D/DG Multistage Centrifugal Pump is the latest type, which is characterized by energy saving, space effective, easy installation, stable performance and so on.
D/DG Multistage Centrifugal Pump Product Introduction:
1.High pressure
2.multistage pump
3.Used for feed water ,boliter feeding ,booster or irrigation.
D/DG Multistage Centrifugal Pump is the latest model. Has the energy conservation, saves the space. Convenient installation. stable performance and other characteristics. The shell adopts 1Cr18Ni9Ti high quality stainless steel. Shaft seal adopts wear-resisting mechanical seal. Zero leakage, long service life. The axial force problem is solved by hydraulic balance. Make the pump run smoothly with low noise. Its installation conditions are more favorable than DL pumps. Can fully meet the high-rise buildings, deep Wells. Mine and other water supply and drainage and fire facilities. As a result, it is all the major industries in the transport of cold and hot water. General media or other physical and chemical properties. The best type of liquid that resembles water.
Multistage Centrifugal Pump Range of Application:
Applicable for boiler water,supply and drainage in municipal projects,factories and mines. industrial cyclic pressurization,distant water transportation. pressurization in high-rises,fire control in constructions, and so on.
Type Designation:
D/DG 46 – 50×12
D :Segmental feed pump.
G :Boiler pump
46 : Designed flow (m3/h)
50 :Single stage lift head (m)
12 : Stage number
Technology Parameters:
Flow:3.75-500m3/h
Head:19-650m
Power:2.2-1050KW.
Rotary speed:14502950r/min
Calibre:40-250mm
Temperature range:≤105°C
