Performance parameters of KCB series cast steel gear pump & cast iron gear pump: flow range: 1.1m3/h~570m3/h;Head range: 60m~145m;Temperature range: 0 ℃ ~ 300 ℃, the Viscosity of 5 x 10-6-1. 5 x 10-3 m2 / s (5 to 1500 CST);Pressure range: 1.45mpa ~ 0.6mpa;Power: 1.5 KW to 250 KW.
KCB Series Cast Steel Gear Pump Cast iron Gear Pump Is Different As Follows:
1.Material is cast steel and cast iron;
2. The maximum temperature of medium resistance of cast steel is 300℃, and the maximum temperature of cast iron is 120℃;
3. Cast steel gear pump corrosion resistance, acid and alkali resistance, cast iron gear pump can only transport ordinary medium.
4. The pumps of the two materials are the same in other aspects. The motors can be selected according to the use environment of ordinary motors and explosion-proof motors.
Performance Parameters:
| Model | Caliber (Inch) | Flow (L/min ) | Pressure (MPa ) | Suction Lift (m ) | Motor power (KW ) |
| KCB18.3 | 3/4 | 18.3 | 1.45 | 5 | 1.5 |
| KCB33.3 | 3/4 | 33.3 | 1.45 | 5 | 2.2 |
| KCB55 | 1″ | 55 | 0.33 | 5 | 1.5 |
| KCB83.3 | 1 1/2″ | 83.3 | 0.33 | 5 | 2.2 |
| KCB135 | 2″ | 135 | 0.33 | 5 | 4 |
| KCB200 | 2″ | 200 | 0.33 | 5 | 4 |
| KCB300 | 3″ | 300 | 0.33 | 5 | 5.5 |
| KCB483.3 | 3″ | 483.3 | 0.33 | 5 | 7.5 |
| KCB483.3 | 3″ | 483.3 | 1.0 | 5 | 11 |
| KCB633 | 4″ | 633 | 0.28 | 5 | 11 |
| KCB960 | 4″ | 960 | 0.3 | 5 | 18.5 |
| KCB1200 | 6″ | 1200 | 0.6 | 3 | 37 |
| KCB1600 | 6″ | 1600 | 0.6 | 3 | 45 |
| KCB1800 | 8″ | 1800 | 0.6 | 2.5 | 55 |
| KCB2500 | 8″ | 2500 | 0.6 | 2.5 | 75 |
| KCB3800 | 10″ | 3800 | 0.6 | 2 | 110 |
| KCB5400 | 10″ | 5400 | 0.6 | 2 | 110 |
| KCB7600 | 14″ | 7600 | 0.6 | 2 | 200 |
| KCB9600 | 14″ | 9600 | 0.6 | 2 | 250 |
KEMAI China Sincerely Provides You With:
Pre-Sales Service:
Professional technical engineers provide accurate and appropriate selection materials free of charge to ensure that customers choose cost-effective products.
In The Sale Service:
Each customer we will be honest, fair, warm, rigorous treatment.Provide comprehensive product information.Arrange production in time to ensure accurate delivery time.We guarantee punctuality, quality and quantity in strict compliance with the terms and conditions stipulated in the contract.
After-Sales Service:
We have established a perfect after-sales service system, 7X24 hours a day for your service.All products installation guide, all day long to meet your needs.All products are guaranteed for one year, free of charge during the warranty period.Supply all kinds of accessories at the lowest cost price for life.
